AOPEN QF50C 4-in-1 CASE SET BEIGE/MIDI TOWER 300W 4X5.25" 2X3.5" ATX -BEIGE WITH BEIGE+BLUE FRONT [P/N 91.97020.C97]
WITH PS/2 KEYBOARD,MOUSE AND SPEAKERS


AOpen barebone chassis feature precise mechanical construction and are ready for FCC system approval. These cases reflect AOpen's commitment to quality and offer resellers a way to build systems of superior quality. Combine AOpen cases with industry-leading AOpen motherboards to get the best fit. PRODUCT FEATURES: High expansion capacity - 7 slots and 7 drive bays; Bend-in edges ensure safe assembly and installation; Smart slide-in back bracket with no screws needed; Compact design saves space; Supports 300/250W(ATX) safety power supply; P4 ready; Complies with FCC Class B, DoC, and CE; Sliding-in/out side covers that make assembly easier.



Product Description AOpen QF 50C - mid tower - ATX
Form Factor System cabinet - mid tower
Dimensions (WxDxH) 19.4 cm x 44 cm x 42.6 cm
Weight 6.9 kg
Supported Mainboard Form Factor ATX
Colour Blue, Beige
Power Provided 300 Watt
Manufacturer Warranty 1 year warranty


Details


General
Form Factor System cabinet - mid tower
Supported Mainboard Form Factor ATX
Internal Bays Qty 1
Front Accessible Bays Qty 6
Width 19.4 cm
Depth 44 cm
Height 42.6 cm
Weight 6.9 kg
Colour Blue, Beige
Fans Rear : 2 x 8 cm
Expansion / Connectivity
Expansion Bays Total (Free) 4 ( 4 ) x front accessible - 5.25" x 1/2H
2 ( 2 ) x front accessible - 3.5" x 1/3H
1 ( 1 ) x internal - 3.5" x 1/3H
Expansion Slots Total (Free) 7 ( 7 ) x Expansion Slot
Interfaces 2 x USB - 4 PIN USB Type A
1 x microphone - input - mini-phone 3.5mm
1 x headphones - output - mini-phone stereo 3.5 mm
Manufacturer Warranty
Service & Support 1 year warranty
Service & Support Details Limited warranty - 1 year
Miscellaneous
Compliant Standards CSA, UL, C-Tick
Power
Power Device Power supply
Power Provided 300 Watt

Keyboard Model Part Number
KB-950P
90.00007.950


Key Features


104-key Windows layout
19 Internet/Media hot keys
Laser engraved printing keys
Programmable hot keys to meet your need
Membrane tactile switch
Multi-lingual available
Ergonomic palm rest included
20 million life cycles


Specifications


Model:KB-950P
Operating Force: 60+/-10gm
Travel Distance: 4+/-0.4mm
Connector: PS/2
Power Rating: 25 mA max@5V
Contact Resistance: 500 Ohm max
Contact Bounce: 11 ms Max
Operating Temperature: 0°C~50°C
Storage Temperature: -20°C~60°C
Humidity: 0% ~ 95% RH, Non-Condensing
Dimensions: 478 mm (L) x 193 mm (W) x 48 mm (H)
                   18.82(L) x 7.60(W) x 1.89(H) inch
Certifications: FCC, CE, C-tick


Optical Mouse


AOpen O-23G is an ambidextrous 3-button optical wheel mouse that plugs into PS/2 or USB port.
The O-23G has an ergonomic and elegant design with its contoured body ensuring the user's comfort. This high precision mouse glides across most surfaces, recording motion optically without a ball or rollers


Key Features

3 buttons (left + right +   wheel button) + 1 wheel
Agilent 800 dpi IC
No tracking ball to clean
Precision optical sensor
Advanced design with programmable buttons
Works on most surface
Smart iWheelWorks program included
Zoom in/out and auto-scroll in Office 97/2000/XP
Windows 95/98/Me/NT/2000/
XP multilingual driver included


Specifications


Model: O-23G
Interface Protocol: PS/2 or USB (requires USB Adaptor)
Current Consumption: 100mA max@5V
Mass weight (with cable): 102g
Switch Life: 1,000,000 cycles
Button: 3 buttons
Cable Length: 160 cm
Electrical MTBF: 150,000 hrs
Mouse Resolution:  800 dpi
Mechanical Life: 500 miles
Operating Systems: Windows 95/98/Me/NT/2000/XP and beyond.
Certifications: FCC Class B, CE, C-Tick

Stereo Speakers

Key Features

140 watts P.M.P.O.
Headphone jack for private listening environment
Single volume control
Magnetically shielded design


Specifications

Drive Units : 3.5" Full Range
P.M.P.O : 140 Watts
Load Impendance : 4 Ohm
Frequency response : 60- 18KHz
Total noise voltage : 0.8mV
Power Supply: AC 6V/200mV
Controls : Power/LED/Volume
Operating Voltage : 110V or 220V
